Meta Aramid Thread – Premium 1313 Meta Aramid Sewing Thread for Flame Retardant & High-Temperature Applications
Meta Aramid Thread, also known as 1313 Meta Aramid thread (or meta-aramid sewing thread), is a high-performance sewing thread engineered for applications where flame resistance and thermal protection are critical. Made from 100% meta-aramid fiber (PMIA, poly-m-phenylene isophthalamide), this 1313 aramid sewing thread delivers inherent flame retardancy that is molecularly built into the fiber structure – it cannot be washed out, worn off, or diminished over time. Whether you search for “meta aramid thread” or “1313 meta aramid thread,” you are looking for the same premium flame-retardant sewing solution trusted by professionals in firefighting gear, protective clothing, military combat suits, and high-temperature industrial textiles.
What Makes 1313 Meta Aramid Thread Exceptional?
Inherent Flame Retardancy: 1313 Meta Aramid thread has a limiting oxygen index (LOI) greater than 28% – well above the 21% oxygen concentration in air. This means the fiber will not sustain combustion in air, does not melt or drip, and is self-extinguishing when removed from the flame source. The flame resistance is inherent to the molecular structure and lasts the lifetime of the thread.
Superior Heat Resistance: Continuous use temperature up to 220°C, with short-term exposure tolerance up to 370°C (700°F). The thread shows minimal thermal shrinkage – approximately 1% at 250°C – maintaining dimensional stability in high-temperature environments. Decomposition begins above 370°C, with carbonization starting around 400°C.
Excellent Electrical Insulation: Meta-aramid thread provides outstanding dielectric strength. The material achieves H-grade insulation rating and is widely used in motor slot insulation, transformer insulation, and cable wrapping tape.
- Chemical & Corrosion Resistance: The chemical structure of aramid 1313 is highly stable, resisting corrosion from most high-concentration inorganic acids, alkalis, hydrolysis, and steam corrosion.
Main Features
- Extremely high LOI
- Comfort to wear
- Thermal protection
- Anti-static
Color:
Original color and dyed
Specifications:
20s/2 20s/3 30s/2 30s/3etc
Tube type:
Loose tube (170mm, 230mm), paper tube
Usage:
Sewing, Quilting
Material:
aramid fiber
Package:
cardboard box, other
Customization:
Specifications and packaging can be customized
Color:
Original color and dyed
Specifications:
20s/2 20s/3 30s/2 30s/3etc
Tube type:
Loose tube (170mm, 230mm), paper tube
Usage:
Sewing, Quilting
Material:
aramid fiber
Package:
cardboard box, other
Customization:
Specifications and packaging can be customized
Available Winding Type
Applications of Meta Aramid Thread
1313 Meta Aramid thread is the preferred choice for safety-critical sewing applications where heat and flame protection are paramount:
Thermal protective clothing (PPE): The stitching of the insulation lining and waterproof breathable layer of the firefighter’s firefighting suit.Arc protection clothing, high-temperature resistant workwear for metallurgical, glass, and ceramic factories.
High temperature filtration and industrial dust removal: This is the largest application market for aramid sewing thread. Used for sewing high-temperature flue gas dust removal filter bags for cement plants, steel plants, and coal-fired power plants.
Aerospace and Transportation: Aircraft seat covers, train car interiors, racing suits, etc
T.D.S.
SIZE
(S for Count)
TEX
(No.)
20s/2
60
16660
1080
20s/3
90
11100
1620
30s/2
40
25000
720
30s/3
60
16660
1080
40s/2
30
33000
540
40s/3
45
22200
810
Table
Construction：1313 Meta Aramid Thread
Size：20s/2
TEX：60
Yield：16660
Average Strength：1080
Size：20s/3
TEX：90
Yield：11100
Average Strength：1620
Size：30s/2
TEX：40
Yield：25000
Average Strength：720
Size：30s/3
TEX：60
Yield：16660
Average Strength：1080
Size：40s/2
TEX：30
Yield：33000
Average Strength：540
Size：40s/3
TEX：45
Yield：22200
Average Strength：810
